500rpm 1A Mini Slip Ring Rotary 6mm 5.5mm 2 4 CH
500rpm 1A Mini Slip Ring Rotary 6mm 5.5mm 2 4 CH
Sale
Sold out
Regular price
$7.99
Regular price
Sale price
$7.99
Unit price
per
Description
Description
Max speed |
500rpm (or higher as request) |
|
Dielectric strength |
500VAC 50Hz 60s |
|
Electrical Noise |
<0.01Q |
|
Rated Torque |
0.1 N.m for 6 CHZ +0.03N.m for every 6 CH added |
|
Temperature range |
-20°C to +80°C |
|
Operating humidity |
60%RH or higher |
|
Contact Material |
Precious metal |
|
Housing material |
Metal |
|
I EC |
IP51 |
|
Customization WhatsApp: +86 13506572000
Circuits, size, Amps, protect degree, rotate speed |
Combined visial transmission, UBS, HDMI, Profibus, ethernet signal |
Combined gas, liquid and other media |
900 in stock
Couldn't load pickup availability
-
All orders are dispatched the next business day!
-
We will beat any price. We back all products with a 1 year guarantee.
